Basic Info.
Product Description
Product Name:
High Quality Corrosion Resistance Electrode Welding Rod
Diameter:
2.5mm, 3.2mm, 4.0mm and 5.0mm
Length:
300mm, 350mm and 400mm
Application:
Used for welding heavy load or low carbon steel thick plate structure and low alloy steel structure, such as machinery, shipbuilding, pressure vessels, etc.
Carbon Stick Welding Electrodes E6013&E7018
| Specifications | 1) All position welding. |
| 2) Excellent welding performacne. | |
| 3) AC/DC |
| Features | E7018 is an outstanding quality all position welding electrode covered with extra Low hydrogen potassium type coating forhigh tensile strength mild steels and low alloy steels. Its nominal weding efficiency is about 110% due iron powder is contained. The weld metal shows an excellent low temperature toughness and high crack -resistance. |
| Delivery Tiime: | Average 30 Days |
| Payment Term | T/T; L/C; Western Union |
| High Quality: | Low price |
| Packaging Detail: | Standard Export |
| Shipping Term: | Fob;CIF;CFR |
| Application | It is widely used in important projects of ships, boilers, high ressure vessels, skyscrapers, offshore drilling platforms, nuclear power plants and so on. The groove of base metal should be cleared impurities away and the elctrode must be baked at a temperature to 400° C then be held 1-2hours before welding. |
Mechanical properties of the deposited metal(%): |
σb ≥ 420MPa σs ≥330MPa δ5 ≥ 17 AKV (J) 0 'C |
general value: (460--540) (≥340) (18-26) ≥47 |
Referenc Current |
diameter: 2.5mm 3.2mm 4.0mm 5.0mm |
current(A): 50-80 80--120 150--190 180240 |
Company Introduction
Our company was established in 2002, and it mainly operates Wusteel, Ansteel,Xinsteel ., Xiangsteel Wuhansteel , Anshansteel Tiansteel Nansteel , XingCheng steel and many high quality products of domestic famous manufacturers.
Our products mainluy contain Low alloy and High-Strenght Steel plate, Carbon Steel Plate, alloy Structure Steel Plate, Bolier and Pressure Vessel steel Plate, Structure Steel Plate, Ship-Building and Oil Platform Steel Plate, Pipe Steel Plate, High Strength and High Toughness Steel Plates, Mold Steel Plates, Corrosion Resistant Plate, Composite Steel Plate and so on.
We operate 12 major series, more than 300 brands, and more than 40 species have filled in the domestic blank, over 80 varieties have substitued import successful, and more than 30 varieties exports to the United States, Japan, Germany and other developed countries and regions. Specification: width: 1500-4020, thickness: 8-700mm, legth: 3000-27000mm. Condition of delivery: according to coustomer's requirements, we can deliver the goods in sevaral conditions, such as hot rolling, normalizing ,tempering, normalized and tempered and so on. Executive stansard: according to coustomer's requirements.
