Basic Info.
Model NO.
E71T-GS
Slag Characteristic
Acidic
Extended Length
<10mm
Product Name
Flux Cored Welding Wire
Model
E71t-GS
Sample
Freely
OEM
Accept
Package
15kg/Carton
Certificate
ISO CE Lr BV TUV
MOQ
5kg
Quality
High Quality(ISO)
Feature
Excellent Welding Performance
Shielding Gas
C02/CO2+Ar
Transport Package
15kg/Spool
Specification
0.8-1.6mm
Trademark
xunzhuo
Origin
China
Production Capacity
5000tons/Month
Product Description
Name:Factory supply Flux Core MIG Wire E71T-GS -0.035 Inch(0.9mm) 10 Pound Spool (5kg spool) Gasless Mild Steel MIG Welding Wire with Low Splatter
Description:
Both E71T-11 and E71T-GS are gasless flux cored welding wires, which are used for welding sheet or thin gauge metal,
robotic / hard automation, general fabrication, especially suit outdoor and windy environment.
Difference:
Accord with AWS requirement, E71T-GS don't have requirements on the strength of welding joint. But generally, the difference is minimal. The choose will mainly depend on client's use preference.
Chemical Composition of All Weld Metal (CO 2): (Wt. %)
| Item | C | Mn | Si | S | P |
| Typical Results | 0.06 | 1.38 | 0.45 | 0.010 | 0.019 |
Mechanical Properties of All Weld Metal (CO 2 ):
| Item | Rel/Rp0.2/MPa | Rm/MPa | A/% | KV2/J | |
| -20ºC | -30ºC | ||||
| Typical Results | 475 | 551 | 29 | 155 | 90 |
Recommended Current (DC+) & Voltage Range
| Welding Position | 1.2MM | 1.6MM | ||||
| Current Range | Voltage Range | CO2 Range | Current Range | Voltage Range | CO2 Range | |
| Flat | 120-230 A | 16-34V | 15-25L/Min | 180-400A | 22-42V | 15-25L/Min |
| Horizontal | 120-280A | 16-29V | 15-25L/Min | 180-400A | 22-42V | 15-25L/Min |
| Overhead | 120-240A | 16-28V | 15-25L/Min | |||
| Vertical Up | 120-240A | 16-27V | 15-25L/Min | 180-260A | 23-30V | 15-25L/Min |
| Vertical Down | 120-260A | 16-29V | 15-25L/Min | 180-260A | 23-30V | 15-25L/Min |
Diameter: 0.8mm, 0.9mm, 1.0mm, 1.2mm, 1.4mm, 1.6mm
Our services
1. Free sample is available
2. OEM service is available
3. High quality and professional service.
4. Much more competitive price.
5. On-time delivery
Feature:
- Welding Made Quick and Easy ... Breeze through your welding project with ease with our flux core MIG welding wire. No need for shielding gas. The flux filling acts as a shielding agent to create beautiful welds; perfect for use outdoors.
- Do Your Best Work ... Color all your clients impressed with the precision and arc control of the E71T-GS gasless MIG welder wire. You'll love the low splatter whether you're performing single or multi-pass welds. Great for T-joints, butt welds & lap welds.
- Unlock a World of Versatility ... Professional welder, metalworking hobbyist, or DIY enthusiast, this gasless MIG wire gives you the freedom to work on multiple projects. It has a 0.035" diameter.
- Get Value for Your Money ... Save big without sacrificing on quality. Our flux core welding wire .035 comes in a 2-pound spool at a fraction of the cost. And unlike others that are haphazardly packed, we package ours with care to prevent annoying tangles.
| Diameter (mm) | Package type | Weight | Package style |
| 0.6 - 1.2mm | Plastic spool - D100 - D200 - D270 | 0.45 / 0.7 / 1 / 5 / 15 kg | Natural packaging OEM Factory brand |
Application:
Suitable for welding key structure steel made of low carbon steel and low-allow steel, specially suitable for welding some key structures like shipbuliding, mechanical manufacture, pressure vessels, boilers, petroleum machinery, chemical machinery, hoisting machinery, etc.
About our company:
Our company is specialized in manufacturing full kinds of welding materials. The production base occupies over 100 acres is in Changsha Hunan, which is adjacent to Guangzhou.
Now the annual output has exceeded 100 thousand tons per year. With the continuous upgrading of production technology and management mode, the company has become the Chinese industry leader for over 60 years. The company have passed many international certifications, including ABS, CE, DB, VD, LR, ISO. It is the first factory in China who gets the certificate of SG2 and SG3 for TUV approval; also the first and one of the few factories in China that can produce ER70s-6 without any welded joints in whole 250kg for drum pack.
The company is specialized in producing full kinds of welding wires and welding electrodes. The products are widely used in vehicles, engineering, mining machinery, furniture, plumbing, electric power facilities, steel structure, shipbuilding, pressure vessels and other industries.
