Basic Info.
Product Description
Product Description
E310-16 electrodes are used to weld stainless steels of similar composition in wrought and cast form. It provides you with outstanding performance for the out-of-position welding of 310 type stainless steels, especially when ease of execution and fine weld appearance are required. The weld deposit is fully austenitic, and as such calls for minimum heat input during welding.
Typical Applications: head shields, furnace parts, ducting
Description:
1) Covering is lime titania tupe for welding of AISI(SUS)310S,SCS 18 and clad side of 18%Cr-8%Ni stainless clad steel.
2)The deposited weld mrtal has perfect austenitic structure.
3)Good mechanicalproperty and heat resistance of the depodited weld metal.
4)Redry the electrode at 250-350ºC for 30-60minutes prior to use.
| Typical chemical composition of all-weld metal(%) | ||||||||
| C | Si | Mn | P | S | Ni | Cr | Mo | Cu |
| 0.11 | 0.40 | 1.86 | 0.025 | 0.013 | 20.82 | 25.59 | 0.12 | 0.09 |
| Typical mechanical properties of all-weld metal | |||||||
| Y.S(0.2%OS) (MPa) | T.S (MPa) | EL(%) | Remarks | ||||
| AWS A5.4 EN ISO 3581-A Example | min.550 | min.30 | |||||
| min.350 | min.550 | min.20 | |||||
| 490 | 620 | 40 | AW | ||||
| AW:As-Welded | |||||||
| Size avaolable and recommended currents(AC or DC +) | ||||||
| Dia. | (mm) | 2.0 | 2.6 | 3.2 | 4.0 | 5.0 |
| Length | (mm) | 250 | 300 | 350 | 350 | 350 |
| Amp. (A) | F | 30~50 | 50~80 | 80~110 | 110~140 | 140~180 |
| V.OH | 25~45 | 45~60 | 70~90 | 90~130 | - | |
2.0*300mm(350mm)
2.5*300mm(350mm)
3.2*350mm
4.0*350mm(400mm)
PACKING:
5kg/inner box,
20kg (4box)/outer carton,
1000kgs=1ton=50 cartons packed on a pallet.
-------------------Our Other Welding Products-------------------
If you are interested, please click on the below picture to enter the link
| FAQ |
Q: What is delivery time / lead time ?
A: 2-3 weeks.
Q: What is your minimum order ?
A: 3000kgs/each size. (MOQ for stainless steel welding electrode)
Q: What is your payment term ?
A: 50% T/T in advance, 50% balance paid before shipment.
Q: Can we visit your factory ?
A: Yes. Welcome to visit our factory at any time.
Q: Can you provide free sampe ?
A: Yes. Free samples are available for you.
