Basic Info.
Model NO.
YQ-D184
Color
Silver
Type
Welded Mesh
Certification
ISO9001
Condition
New
Transport Package
Waterproof Paper& Shrink Film; Plastic Film.
Specification
opening: 1/2′′ 1′′ 3/4′′
Trademark
YQ
Origin
China
HS Code
7314310000
Production Capacity
3000 Rolls Per Month
Product Description
1.6mm 1 Inch Galvanized Welded Wire Mesh 30m Roll
Product Introduction:
Galvanized welded wire mesh is made of high quality low carbon steel wire.welded wire mesh divides into hot dipped galvanized and electro galvanized.The adoption plates the zinc craft after welding,it is made from high-quality iron wire by automatic equipment .The products have smooth mesh surface ,well-proportionedmeshes,
strong welded points and bright luster.The mesh does not come loose even if cut in parts or being exerted force on parts .Compared with general iron wire,the products are better in respects of anti-corrosive and anti rust.
Specification:
Characteristics:
1.Good oxidation resistance.
2.Good corrosion resistance.
3.Smooth mesh surface.
4.Well-proportioned meshes.
5.Anti-corrosive and anti-rust.
6.Strong welded points and bright luster, Solder joint firm.
Application:
Galvanized welded wire mesh is for garden, feeding agriculture, fishing, poultry, mine field, lawn cultivation, profession's guard, decorate machine protection. Special welded wire mesh ,(Heavy)welded wire mesh panel service as fencing mesh for transportation industry, construction a agriculture.
Product Introduction:
Galvanized welded wire mesh is made of high quality low carbon steel wire.welded wire mesh divides into hot dipped galvanized and electro galvanized.The adoption plates the zinc craft after welding,it is made from high-quality iron wire by automatic equipment .The products have smooth mesh surface ,well-proportionedmeshes,
strong welded points and bright luster.The mesh does not come loose even if cut in parts or being exerted force on parts .Compared with general iron wire,the products are better in respects of anti-corrosive and anti rust.
Specification:
| Product name | Factory Direct Supply Galvanized Iron Welded Wire Mesh |
Material | Iron wire, stainless steel wire and aluminum-magnesium alloy wire. |
Color | Silve,green etc |
| Surface treatment | Hot-dipped galvanized, electro galvanized and PVC coated |
Wire diameter | 0.5-1mm |
Hole size | 1/4 inch - 2 inch. Also accept other custom size. |
Welded trpes | Gal. after welded or gal. before welded. |
| Feature |
|
| Application |
Machinery protection guards. Construction protection. Slab reinforcement. Reinforcing walls. Floor heating system. Plaster mesh. Plant climbing support. Gridwall panel or display panel. Animal cage and bird aviary in the zoo. Garden fence. Stair rail infill panel. Wire container. Wire decking. Welded gabion. |
| MESH | WIRE DIAMETER (BWG) | WIDTH | LENGTH | |
| (INCH) | (MM) | 24", 36", 48", 60",72" OR 0.5M, 0.6M, 0.7M, 0.8M, 1.0M, 1.2M, 1.5M, 1.8M, 2.0M | 10', 25', 50', 100', 150' OR 5M, 10M, 25M, 30M, 45M | |
| 1/4 × 1/4 | 6.35 × 6.35 | 22,23,24,25 | ||
| 3/8 × 3/8 | 10.6 × 10.6 | 19,20,21,22 | ||
| 1/2× 1/2 | 12.7 × 12.7 | 16,17,18,19,20,21,22,23,24 | ||
| 5/8 × 5/8 | 16 × 16 | 18,19,20,21,22 | ||
| 3/4 × 3/4 | 19 × 19 | 16,17,18,19,20,21 | ||
| 1 × 1/2 | 25.4 × 12.7 | 16,17,18,19,20,21 | ||
| 1 × 1 | 25.4 x 25.4 | 14,15,16,17,18,19,20 | ||
| 1-1/2 × 1-1/2 | 38 x 38 | 14,15,16,17,18,19 | ||
| 1 X 2 | 25.4 × 50.8 | 14,15,16,17,18,19 | ||
| 2 × 2 | 50.8 × 50.8 | 14,15,16,17,18 | ||
| 2 × 3 | 50.8 x 76 | 14,15,16 | ||
| 4 × 4 | 101.6 x 101.6 | 12,14,15,16 | ||
| 6 × 6 | 152.4 x 152.4 | 10,12,14,16 | ||
Characteristics:
1.Good oxidation resistance.
2.Good corrosion resistance.
3.Smooth mesh surface.
4.Well-proportioned meshes.
5.Anti-corrosive and anti-rust.
6.Strong welded points and bright luster, Solder joint firm.
Application:
Galvanized welded wire mesh is for garden, feeding agriculture, fishing, poultry, mine field, lawn cultivation, profession's guard, decorate machine protection. Special welded wire mesh ,(Heavy)welded wire mesh panel service as fencing mesh for transportation industry, construction a agriculture.
