Basic Info.
Model NO.
0.030
Extended Length
10-20mm
Model No.
Er70s-6 Welding Wire
Tensile Strength
545MPa
Yield Strength
452MPa
Elongation
29%
Ballistic
91%
Flux Content
International Standard
Transport Package
Roll and Carton
Specification
CE SGS ISO
Trademark
KYA
Origin
Changzhou China
HS Code
72292000
Production Capacity
500 Tons Per Month
Packaging & Delivery
Package Size
50.00cm * 50.00cm * 50.00cm
Package Gross Weight
16.000kg
Product Description
Specifications:
| Product Name | WELDING WIRE ( MIG WELDING WIRE| MIG WIRE ) |
| ER70S-6 | |
| CO2 Gas Shielding | |
| Welding Product| Welding Materials| Welding Consumable | |
| Executive Standard | GB/T 8110 ER50-6/ AWS A5.18 ER70S-6/JIS Z3312 YGW12 |
| Approval Certificate | CCS, ABS, NK, KR, LR, GL, DNV, ISO9001, ISO14001, OHSAS18001 |
| Size | 0.80mm |
| Package | 15kg/D270 Plastic Spool, 16kg/box, 72boxes/pallet, 24pallets/1x20'GP |
| Net Weight: 25.92tons for 1x20'GP | |
| Gross Weight: 27.80tons for 1x20'GP | |
| Price Terms | CIF, CFR, FOB, conforming to INCOTERMS2010 Rules |
| Terms of Payment | 30% T/T in advance, 70% balance against B/L copy, or L/C |
| Lead Time | within 15~35days after receipt of deposit |
Welding Wire Specs:
| Package | ||
| Specification | Wire Tray | Weight |
| φ1.0-1.6mm | D100mm D200mm D270mm D300mm K300mm | 1kg,5kg,15kg,17kg,18kg,20kg |
| Wire Chemical Composition(%) | ||||
| C | Mn | Si | P | S |
| ≤0.18 | ≤1.75 | ≤0.90 | ≤0.03 | ≤0.03 |
| Diameter(mm) Parameters | 1.2mm | 1.4mm | 1.6mm | |||
| Welding position | Flat | Vertical-up | Flat | Vertical-up | Flat | Vertical-up |
| Voltage(Volt) | 28-36 | 25-26 | 28-38 | 25-28 | 30-40 | 26-30 |
| Current(Amp) | 150-300 | 150-220 | 180-350 | 150-230 | 200-400 | 160-250 |
| Stickout(mm) | 10-15 | 15-20 | 15-30 | |||
| Flow Rate(l/min) | 15-25 | 15-25 | 15-25 | |||
Applications:
Mechanical Properties of Deposited Metal:
| Tensile strength Rm(Mpa) | Yield strength Rel or Rp0.2(Mpa) | Elongation(%) | Ballistic work(J) | Test Temp. | Shielding Gas |
| 545 | 452 | 29 | 91 | -30ºC | CO2 |
